CXS2209040L30-R08W0.5-A-234
商品櫥窗
CXS2209040L30-R08W0.5-A-234
商品說明
CXS2209040L30-R08W0.5-A-234
Rated/Max Input Power.
0.5W /0.8W
Rated Impedance.
8Ω ± 15%
Sound Pressure Level.
91dB(0.1W/0.1m) ± 3 dB at AVE 0.8K 1.0K 1.2K 1.5K Hz
Resonance Frequency (Fo).
1000±20%Hz
Frequency
Range
.
F0~20kHz.
